CöLöRs offers ready to use UV ink which gives a matt effect, thus an additional process of matt spot varnishing can be eliminated. The quality and depthness achieved is incomparable and much higher than that delivered by conventional printing.
Substrates: Pretreated PE, PP and PS.
Properties: Oil based quick setting pad printing inks.
Application:
Color Shades Product Code PRIMROSE YELLOW CMC11001 LEMON YELLOW CMC11002 PERMANENT YELLOW CMC11003 GOLDEN YELLOW CMC11004 WARM YELLOW CMC11005 FLAG ORANGE CMC11006 UNIVERSAL ORANGE CMC11007 FIRE ORANGE CMC11008 BRILLIANT RED CMC11009 PERMANENT RED CMC11010 POPULAR RED CMC11011 DEEP RED CMC11012 PEACOCK BLUE CMC11013 SKY BLUE CMC11014 ROYAL BLUE CMC11015 PERMANENT BLUE CMC11016 INDIA BLUE CMC11017 BRONZE BLUE CMC11018 RICH ROYAL BLUE CMC11019 POPULAR VIOLET CMC11020 BRIGHT VIOLET CMC11021 PERMANENT VIOLET CMC11022 UNIVERSAL VIOLET CMC11023 PURPLE CMC11024 VIVID GREEN CMC11025 BRIGHT GREEN CMC11026 COCOA BROWN CMC11027 INTENSE BROWN . CMC11028 AQUA TINT CMC11029 SEA TINT CMC11030 GRASS TINT CMC11031 BISCUIT TINT CMC11032 BADAM TINT CMC11033 ROSE PINK CMC11034 STEEL GREY CMC11035 PROCESS YELLOW CMC11036 PROCESS MAGENTA CMC11037 PROCESS CYAN CMC11038 PROCESS BLACK CMC11039 DENSE BLACK CMC11040 BRIGHT MAGENTA CMC11041 Screen
The recommended mesh is 90 to 120 threads/cm (230 threads/in to 305 threads/ in).
Squeegee
Recommended with this ink : single, double or triple durometer polyurethane blades with hardness between 85 and 75 shores.
Drying Time
1 to 3 min at ambient temperature.
Reducing Aid
Various diluents are available according the needed curing speed :
Fast curing : ECO Rapide R
Medium curing : ECO Moyen M
Slow curing : ECO Lent L
Retarder : ECO Retardeur RTDRetarding Aid
Detail will come here
Cleaning
COLORS standard cleaning solvents are : Solvent H, ECO N Solvent and 93801 solvent.
Technical Specifications:
Mesh : 140
Shades : Available on request
Conveyor Speed : 20 – 30 Meters /min
Lamps : 1
Lamp Int : 300 watt/inch
Substrates : Can be formulated accordingly.
Shelf Life : 3 months from the date of manufacturing.
Light Fastness : 4-5 (wool scale).
Storage : Store at moderate temperatures in a dry, well ventilated area and away from direct sunlight.Pre-cautions : Use of gloves and eye wear is recommended.
Important Note : Strictly for over printing only. Cannot be overprinted.
Additional information : The information provided is based on extensive laboratory testing. Cure speeds depends on condition of UV lamps, reflectors, opacity and film thickness. We recommend that you pretest any ink prior to beginning a production run.
Technical Literature : # 400.05.00
Standard and Legislation’s :
Shelf Life: 12 months from the date of manufacturing.
Storage: Store at moderate temperatures in a dry, well ventilated area and away from direct sunlight.
Pre-cautions : Use of gloves and eye wear is recommended.
Important Note : Strictly for over printing only. Cannot be overprinted.
Additional information : The information provided is based on extensive laboratory testing. Cure speeds depends on condition of UV lamps, reflectors, opacity and film thickness. We recommend that you pretest any ink prior to beginning a production run.
Standard and Legislations: For full details about our inks’ conformity with current standards, please refer to the document ECO SYSTEM LABEL by COLORS
Material safety data sheet available at : info@colorsuv.comCOLORS guarantee the quality of our products. We cannot however guarantee the finished results because we exercise no control over an individual operating procedures. Our responsibility is limited solely to the exchange of ink or varnish. The quality of a substrate to be printed can vary, as can an ink being overprinted; therefore the above information is given in good faith based on the state of our art and prior experience. This statement also applies to our technical assistance. When using our inks and varnishes on a new substrate or when changing operating procedures, we strongly recommend testing before use in a production situation to ensure full compatibility. Please refer to our General Conditions of Sales.
