SSUVPP Inks are for container and other applications having resistance to different chemicals, lubricants along with wear and tear. Inks with high LF values available on request.
Substrates: Treated PP and PE.
Application:
Color Shades Product Code S/S UV PVC PROCESS CYAN CMC 42645 S/S UV PVC PROCESS YELLOW CMC 42646 S/S UV PVC PROCESS MAGENTA CMC 42647 S/S UV PVC PROCESS BLACK CMC 42648 S/S UV PVC PAN. YELLOW C CMC 43842 S/S UV PVC PAN. 012 YELLOW C CMC 43843 S/S UV PVC PAN. 021 C ORANGE CMC 43844 S/S UV PVC PAN. WARM RED C CMC 43845 S/S UV PVC PAN. 032 C RED CMC 43846 S/S UV PVC PAN. RUBINE RED C CMC 43847 S/S UV PVC PAN. RHOD. RED C CMC 43848 S/S UV PVC PAN. PURPLE C CMC 43849 S/S UV PVC PAN. VIOLET C CMC 43850 S/S UV PVC PAN. 072 C BLUE CMC 43851 S/S UV PVC PAN. REFLEX BLUE C CMC 43852 S/S UV PVC PAN. PROCESS BLUE C CMC 43853 S/S UV PVC PAN. GREEN C CMC 43854 S/S UV PVC PAN. BLACK C CMC 43855 S/S UV PVC JET BLACK CMC 48146 S/S UV PVC MIXING INK CMC 43857 S/S UV PVC WHITE CMC 42649 S/S UV WINDOW YELLOW CMC 47795 S/S UV WINDOW RED CMC 48712 Technical Specifications
Screen : The recommended mesh is 140 to 165 Polyester.
Conveyor Speed : 20 – 30 Meters /min
Lamps : 1
Lamp Int : 300 watt/inch
Light Fastness : 4-5 (wool scale) extra light fast inks available on request.
Squeegee : Recommended with this ink : single, double or triple durometer polyurethane blades with hardness between 85 and 75 shores.
Reducing Aid : CMC-41031 UV Reducing Aid (approx 5-10%)
Curing Promoter : CMC-41033 UV Photo Initiator (approx 3-5%)
Adhesion Promoter : CMC-48936 UV Adhesion Additive (approx 1-2%)
Cleaning : CMC-41315 UV Wash.
Standard and Legislation’s :
Shelf Life: 12 months from the date of manufacturing.
Storage: Store at moderate temperatures in a dry, well ventilated area and away from direct sunlight.
Pre-cautions : Use of gloves and eye wear is recommended.
Important Note : Strictly for over printing only. Cannot be overprinted.
Additional information : The information provided is based on extensive laboratory testing. Cure speeds depends on condition of UV lamps, reflectors, opacity and film thickness. We recommend that you pretest any ink prior to beginning a production run.
Standard and Legislations: For full details about our inks’ conformity with current standards, please refer to the document ECO SYSTEM LABEL by COLORS
Material safety data sheet available at : info@colorsuv.comCOLORS guarantee the quality of our products. We cannot however guarantee the finished results because we exercise no control over an individual operating procedures. Our responsibility is limited solely to the exchange of ink or varnish. The quality of a substrate to be printed can vary, as can an ink being overprinted; therefore the above information is given in good faith based on the state of our art and prior experience. This statement also applies to our technical assistance. When using our inks and varnishes on a new substrate or when changing operating procedures, we strongly recommend testing before use in a production situation to ensure full compatibility. Please refer to our General Conditions of Sales.
