Water Droplet Uv
-
Water Droplet Uv.
Water Droplet Uv. also known as Embossed UV is applicable to highlight specific areas of prints. It has a smooth finish and gives a raised effect when printed.
Available for Paper Base: CMC-40070 and Laminated Base: CMC- 41518
Application:
Technical Specification
Screen : The recommended mesh is 43 + 150 Micron Film.
Conveyor Speed : 20 – 30 Meters /min
Lamps : 1
Lamp Int : 300 watt/inch
Light Fastness : 4-5 (wool scale) extra light fast inks available on request.
Squeegee : Recommended with this ink : single, double or triple durometer polyurethane blades with hardness between 85 and 75 shores.
Reducing Aid : CMC-41031 UV Reducing Aid (approx 5-10%)
Curing Promoter : CMC-41033 UV Photo Initiator (approx 3-5%)
Adhesion Promoter : CMC-48936 UV Adhesion Additive (approx 1-2%)
Cleaning : CMC-41315 UV Wash.
Standard and Legislation’s :
Shelf Life: 12 months from the date of manufacturing.
Storage: Store at moderate temperatures in a dry, well ventilated area and away from direct sunlight.
Pre-cautions : Use of gloves and eye wear is recommended.
Important Note : Strictly for over printing only. Cannot be overprinted.
Additional information : The information provided is based on extensive laboratory testing. Cure speeds depends on condition of UV lamps, reflectors, opacity and film thickness. We recommend that you pretest any ink prior to beginning a production run.
Standard and Legislations: For full details about our inks’ conformity with current standards, please refer to the document ECO SYSTEM LABEL by COLORS
Material safety data sheet available at : info@colorsuv.comCOLORS guarantee the quality of our products. We cannot however guarantee the finished results because we exercise no control over an individual operating procedures. Our responsibility is limited solely to the exchange of ink or varnish. The quality of a substrate to be printed can vary, as can an ink being overprinted; therefore the above information is given in good faith based on the state of our art and prior experience. This statement also applies to our technical assistance. When using our inks and varnishes on a new substrate or when changing operating procedures, we strongly recommend testing before use in a production situation to ensure full compatibility. Please refer to our General Conditions of Sales.
